The Geysers, CA
May 8, 1999
Control room of the ~30MW West Ford Flat power plant |
|
Calpine plant operator teaching the students about the power plant |
|
Water level in the power plant condenser |
|
H2S abatement system at West Ford Flat |
|
Spare stationary blades for the 15MW turbines |
|
Three cooling tower pumps. Two are in use, one is for stand-by |
|
Forced draft cooling tower |
|
Tree damage as a result of geothermal surface manifestations |
|
Fauna in the hot water stream |
|
Kewen Li (Stanford Geothermal Program) with Alfred Truesdell |
|
Water extracted from the creek for injection |
|
The injection line runs from the storage tank to the injection well |
|
Different sized casings at the well head |
|
The first commercial well drilled at The Geysers, still in operation |
|
An uncontrolled well vents steam from a silencer. This well was drilled on unstable ground |
|
An injection well |
|
Further extraction of creek water for injection into the reservoir. Water is taken from 10ft below the creek bottom, using the gravel bed as a natural filter. The clean water is then pumped up to the injection well |
|
Pumps used to lift the creek water up to the injection well |
|
Overlook of The Geysers |
|
Overlook of The Geysers |
